HZS50 Multi Functional Concrete Plant Equipment, High Performance Central Mix Concrete Plant
HZS50 Multi Functional Concrete Plant Equipment with feeding system, measuring system, mixing system, electrical system and auxiliary equipment(such as air compressor, water pump, etc).They are used to transport, feed, store, batch, weigh, mix and discharge the concrete raw materials: cement, water, sand, crushed stone, admixture and additive.
Main Parameter Information of of HZS50 Multi Functional Concrete Plant Equipment
| Model | HZS50 |
| Productivity | 50m³/h |
| Type of Mixer | JS1000 |
| Mixing Volume(L) | 1000 |
| Feeding Way | Skip Hopper |
| (Bucket Type) |
| Discharge Height(m) | 3.8 |
| Aggregate Bins | 3/4 |
| Aggregate Weighing Range(kg) | 1000 |
| Cement Weighing Range(kg) | 600 |
| Max. Aggregate Size(mm) | 80/60 |
| Total Power(kw) | 64.8 |
| Total Weight(T) | 18 |
Featues of HZS50 Multi Functional Concrete Plant Equipment
1. Power:380V,50HZ,3 Phase
2. 37 KW Mixing Power + 15KW Lifting Power Double shafts concrete mixer machine with 3.8-4.2m discharge height,pneumatic discharge grate.
3. PLD1600 with 3-4 storage bins, 4.5m3 concrete mixer,water and additive weighing system,control system,
4. 50t, 100t, 150t, 200t, etc is optional, and we can customize your requirements. Bolted type, modular making with dust collector, broken arch, pressure relief valve, level gauge. Butterfly valve.Φ219mm*8m*11KW screw conveyor
5. Aggregate Bins has adopted electric weighing with sensor,the batching aggregates can be automatically be applied for correction and measure
After-sales service of HZS50 Multi Functional Concrete Plant Equipment
1. Provide 7 * 24 hours online after-sales service every week
2. Provide relevant certificates, customs clearance documents, operation and maintenance instructions, installation videos etc.
3. Dispatch after-sales engineers to install and commission equipment abroad, and provide free training for operators and maintenance personnel for operation and maintenance
4. Establish a complete customer profile, regular inspections, regular visits, free maintenance services and technical improvements
FAQ of of HZS50 Multi Functional Concrete Plant Equipment
Q: What’s the warranty time?
From the date of shipment, 1 year or 1500working hours, whichever comes first.
Q: What’s your payment term?
We accept T/T(30% down payment and balance before shipping) and L/C mostly, but if you prefer other payment terms please contact us for further information.
Q: How long is your delivery time?
Usually, it is 7-10 workdays if the goods are in stock, or it is 15-20 working days if the goods are not in stock, it is according to quantity.
Q: Can we paint our label on your product?
Of course. OEM and ODM are acceptable, please send us your logo or brand, we’ll paint for you.
Q: What`s your advantages?
A: We are manufacturer focused on technology developing, industrial machine manufacturing and trading. The company has devoted itself in concrete mixing machine industry more than 30 years. Now, the company has more than 100 employees while all team leaders and above.And engaged in foreign trade export for many years.
Q: What kind of products do you have?
1. Stationary concrete batching plant arranges from HZS25 to HZS180.
2. Mobile concrete batching plant.
3. Concrete mixer machine.
4. Portable drum concrete mixer with diesel engine.
5. Spare parts including screw conveyor and bolted cement silo.
